REQUIRED HARDWARE. Can be used in longer cases with the use of a SPACER.
CTI M1540 Imax Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L3 Certification to buy.
Brandname | Pro75 6819M1540-P | Manufacturer | Cesaroni Technology |
Man. Designation | 6819M1540-P | CAR Designation | 6819-M1540-P |
Test Date | 5/4/2009 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 75.00 x 757.00 mm (2.95 x 29.80 in) |
Loaded Weight | 5906.00 g (206.71 oz) | Total Impulse | 6819.40 Ns (1534.37 lb-s) |
Propellant Weight | 3624.40 g (126.85 oz) | Maximum Thrust | 2328.80 N (523.98 lb) |
Burnout Weight | 2128.00 g (74.48 oz) | Avg Thrust | 1537.10 N (345.85 lb) |
Delays Tested | plugged | ISP | 191.86 s |
Samples per second | 1000 | Burntime | 4.44 s |
Notes | 33% M |
