REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI K570-17A Classic Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L2 Certification to buy.
Brandname | Pro54 2060K570-17A | Manufacturer | Cesaroni Technology |
Man. Designation | 2060K570-17A | CAR Designation | 2060-K570-17A |
Test Date | 12/3/2002 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 54.00 x 488.00 mm (2.13 x 19.21 in) |
Loaded Weight | 1685.00 g (58.98 oz) | Total Impulse | 2062.90 Ns (464.15 lb.s) |
Propellant Weight | 990.00 g (34.65 oz) | Maximum Thrust | 892.67 N (200.85 lb) |
Burnout Weight | 652.00 g (22.82 oz) | Avg Thrust | 574.00 N (129.15 lb) |
Delays Tested | 29 - 6 secs | ISP | 212.50 s |
Samples per second | 1000 | Burntime | 3.59 s |
Notes | Classic™ |
