REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI J280-16A Smokey Sam Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L2 Certification to buy.
Brandname | Pro54 716J280-16A | Manufacturer | Cesaroni Technology |
Man. Designation | 716J280-16A | CAR Designation | 716-J280-16A |
Test Date | 7/6/2003 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 54.00 x 236.00 mm (2.13 x 9.29 in) |
Loaded Weight | 954.00 g (33.39 oz) | Total Impulse | 716.50 Ns (161.21 lb.s) |
Propellant Weight | 512.00 g (17.92 oz) | Maximum Thrust | 321.10 N (72.25 lb) |
Burnout Weight | 403.00 g (14.11 oz) | Avg Thrust | 282.00 N (63.45 lb) |
Delays Tested | 19 - 6 secs | ISP | 142.70 s |
Samples per second | 1000 | Burntime | 2.54 s |
Notes | Smoky Sam™ |
