REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI J210-16A Classic Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname | Pro54 836J210-16A | Manufacturer | Cesaroni Technology |
Man. Designation | 836J210-16A | CAR Designation | 836-J210-16A |
Test Date | 10/17/2002 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 54.00 x 236.00 mm (2.13 x 9.29 in) |
Loaded Weight | 842.00 g (29.47 oz) | Total Impulse | 836.00 Ns (188.10 lb.s) |
Propellant Weight | 396.00 g (14.00 oz) | Maximum Thrust | 335.00 N (75.38 lb) |
Burnout Weight | 403.00 g (14.11 oz) | Avg Thrust | 210.00 N (47.25 lb) |
Delays Tested | 17 - 6 secs | ISP | 403.00 s |
Samples per second | 1000 | Burntime | 3.99 s |
Notes | Classic™ |
