REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI I140-14A Skidmark Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname
| Pro54 396I140-14A | Manufacturer | Cesaroni Technology |
Man. Designation | 396I140-14A | CAR Designation | 396-I140-14A |
Test Date | 2/4/2010 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 54.00 x 143.00 mm (2.13 x 5.63 in) |
Loaded Weight | 564.3 g | Total Impulse | 395.6 Ns (88.9 lb-s) |
Propellant Weight | 210.4 g | Maximum Thrust | 164.0 N (36.9 lb) |
Burnout Weight | 325.1 g | Avg Thrust | 137.1 N (30.8 lb) |
Delays Tested | 14 - 4 secs | ISP | 191.79 s |
Samples per second | 1000 | Burntime | 2.89 s |
Notes | Skidmark™ |
