REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI I120-15A Imax Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname | Pro54 502I120-15A | Manufacturer | Cesaroni Technology | Man. Designation | 502I120-15A | CAR Designation | 502-I120-15A | Test Date | 10/24/2009 | | | Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 54.00 x 143.00 mm (2.13 x 5.63 in) | Loaded Weight | 623.2 g | Total Impulse | 501.8 Ns (112.8 lb-s) | Propellant Weight | 263.1 g | Maximum Thrust | 152.0 N (34.2 lb) | Burnout Weight | 323.2 g | Avg Thrust | 122.2 N (27.5 lb) | Delays Tested | 5 to 15 | ISP | 194.49 s | Samples per second | 1000 | Burntime | 4.12 s | Notes | Imax™ |
|
| |
