REQUIRED CASING. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI H123-14A Skidmark Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname | Pro38 232H123-14A | Manufacturer | Cesaroni Technology |
Man. Designation | 232H123-14A | CAR Designation | 232 H123-14A |
Test Date | 8/7/2008 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 38.00 x 186.00 mm (1.50 x 7.32 in) |
Loaded Weight | 297.00 g (10.40 oz) | Total Impulse | 232.40 Ns (52.29 lb/s) |
Propellant Weight | 123.00 g (4.31 oz) | Maximum Thrust | 153.30 N (34.49 lb) |
Burnout Weight | 155.00 g (5.43 oz) | Avg Thrust | 122.50 N (27.56 lb) |
Delays Tested | "14,11,9,7,5" | ISP | 192.60 s |
Samples per second | 1000 | Burntime | 1.90 s |
Notes | Skidmark™ |
Earn Reward Points: 54
Earn Discount: $1.62
