REQUIRED CASING. This motor has an adjustable delay which requires a DRILL TOOL. Can be used in longer cases with the use of a SPACER.
CTI H120-14A Red Lightning Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname | Pro38 261H120-14A | Manufacturer | Cesaroni Technology |
Man. Designation | 261H120-14A | CAR Designation | 261-H120-14A |
Test Date | 7/4/2008 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 38.00 x 186.00 mm (1.50 x 7.32 in) |
Loaded Weight | 295.0 g (10.4 oz) | Total Impulse | 260.7 Ns (58.61 lb.s) |
Propellant Weight | 136.6 g (4.82 oz) | Maximum Thrust | 149.4 N (33.59 lb) |
Burnout Weight | 154.0 g (5.43 oz) | Avg Thrust | 121.4 N (27.29 lb) |
Delays Tested | "14,11,9,7,5" | ISP | 194.6 s |
Samples per second | 1000 | Burntime | 2.15 s |
Notes | Red Lightning™ |
