REQUIRED CASING and CLOSURE. This motor has an adjustable delay which requires an ADAPTER RING to use with the DRILL TOOL.
CTI H340-14A Smokey Sam Rocket Motor. This item requires hazmat shipping via FedEx.
This motor requires a L1 Certification to buy.
Brandname | Pro29 287H340-14A | Manufacturer | Cesaroni Technology |
Man. Designation | 287H340-14A | CAR Designation | 287-H340-14A |
Test Date | 6/26/2009 | | |
Single-Use/Reload/Hybrid | Reloadable | Motor Dimensions mm | 29.00 x 365.00 mm (1.14 x 14.37 in) |
Loaded Weight | 391.00 g (13.69 oz) | Total Impulse | 287.30 Ns (64.64 lb/s) |
Propellant Weight | 206.70 g (7.23 oz) | Maximum Thrust | 447.50 N (100.69 lb) |
Burnout Weight | 181.00 g (6.34 oz) | Avg Thrust | 340.60 N (76.64 lb) |
Delays Tested | "14,11,9,7,5" | ISP | 167.38 s |
Samples per second | 1000 | Burntime | 0.84 s |
Notes | Smoky Sam™ |
