Aerotech J520W-13A White Lightning Rocket Motor


Product Information
Specification

Required Hardware

This motor requires a L2 Certification to buy.

The AeroTech Reloadable Motor System RMS is an aluminum cased reusable motor in kit form that is assembled by the user. You will need AeroTech RMS-38/1080 motor hardware to build and complete the motor for many reliable flights. Motor hardware is available separately in a complete set, and also as individual parts. This motor requires installing a 38mm Forward Seal Disc during assembly. Important: High Power RMS reload kits are not compatible with Mid Power RMS products. You will need to set the desired delay time using the 18-38mm Delay Drilling Tool (RDDT), not included.

This RMS motor reload utilizes RCSs exclusive White Lightning™ aerospace grade composite propellant formulation, which produces a gorgeous bright white flame with lots of dense white smoke and a throaty roar at lift-off.

The AeroTech motor reload kit comes with 1 rocket motor reload. Reload kits include all internal motor components and FirstFire™ Initiators. This AeroTech motor is U.S. mailable with no hazmat fee!

Certified by the Tripoli Rocketry Association (TRA), the National Association of Rocketry (NAR) and the Canadian Association of Rocketry (CAR).

  • Specifications:

    Motor Diameter: 1.5 inches (38mm)

    Casing Length: 18.85 inches (479mm)

    Hardware Required: RMS-38/1080

    Total Impulse: 730.6 N-sec

    Average Thrust: 569.6 newtons

    Peak Thrust: 1022 N-sec

    Thrust Duration: 1.3 seconds

    Delay Time: adjustable up to 13 seconds

    Propellant Weight: 381 grams

    Motor Weight: 773 grams

Earn Reward Points: 115

Earn Discount: $3.45

Product Code2174
ManufacturerAerotech Rocketry
ConditionNew
Weight1.4Lb
